Engine

Model

Weichai WP4G95E221

Type

Direct injection, turbocharged, Water cooled

Rated power

70kW

Rated speed

2200rpm

Peak torque

380N·m@1500rpm

Displacement

5.9L

Rated fuel consumption

216g/Kw.h

Emission Norms

Tier II / Euro-III

Main Technical Specification

Loading

Rated load

1700kg

Operating weight

7600kg

Max. lifting capability

3400kg

Rated bucket capacity

1.0m3

Max. breakout force

>60kN

Max. dump clearance

2714mm

Dump reach

845mm

Dump angle at any position

≥43.5°

Min. turning radius

—–Outside of bucket

5670mm

—–outside of rear wheel

4380mm

Lifting time of bucket

≤4.5s

Lowering time of bucket

≤3.5s

Dumping time

≤1.5s

Digging

Rated bucket capacity

0.3m3

Max. digging depth

4405mm

Max. digging force

>50±10％kN

Max. digging radius

5481mm

Max. dumping height

3737mm

Transmission System

Torque Converter

Model

CARRARO

Torque ratio

2.55

Cooling type

Pressure oil circulating

Gear box

Model

CARRARO

Type

Synchromesh mechanical shift

Gear shifts(Forward/Reverse)

F4/R4

Traveling speed(km/h)

Forward/ReverseⅠ

6.0/6.0

Forward/ReverseⅡ

9.6/9.6

Forward/ReverseⅢ

20.5/20.5

Forward/ReverseⅣ

38/38

Axle and Tire

Model

CARRARO (4×4)

Type of main reducer

Spiral bevel gear, single stage

Type of final reducer

Single stage planetary

Max. tractive force

70KN

Tire size

Front tire 12-16.5NHS ，Rear tire 19.5L-24R4

Working Equipment

Model of oil pump

JHP2063C

System pressure

23Mpa

Model of loading valve

ZL20.3S4C-00

Model of digging valve

ZL30DC-07

Steering System

Type

Front wheel steering

Model of steering pump

JHP2063C

Model of steering gear

BZZ5-E160B+FKB-3022

System pressure

14Mpa

Dimensions

Length (with bucket on ground)

7085mm

Width

2313mm

Height (To the top of the cab)

2720mm

Height (To the top of the digging pole)

3424 mm
